GIMLET Series Enter SP mode.pdf
GIMLET Series Enter SP mode.pdf
CONFIDENTIAL - Ricoh Family Group internal use only GIMLET Series MF Models Enter SP mode: Gim-MF1d (GW+) Press the "Reset" key, "8" "0" "6" "1" "8" "2" key in sequence, then press "Clear" key for more than 3 seconds. Gim-MF1a/b (KIBO) Press the "Reset" key, "8" "0" "6" "1" "8" "2" key in sequence, then press "Clear" key for more than 3 seconds. Enter "Special Service Mode": Press the "Reset" key, "8" "0" "6" "1" "8" "2" key in sequence, then press "Clear" key for more than 3 seconds, press “#” simultaneous with “System SP” button. Enter "Factory mode": Press "C", "143", "C", "STOP", "C", "STOP", "STOP..." (3 sec.) 4.3 inch uWVGA model Enter SP mode: Gim-P1d (GW+) 4.3 inch uWVGA Press the "Home" key and "Simple Screen" key simultaneously for more than 3 seconds, then press "User Tools" key. Enter "Special Service Mode": Power the machine “ON” while pressing “Home” and “Simple screen” key together for more than 3 seconds, then press and hold the “Simple Screen” key for more than 3 seconds. Enter "Factory mode": Power the machine “ON” while pressing “User Tool” and “Simple screen” key together for more than 3 seconds. 4 line LCD models Enter SP mode: Gim-P1a (KIBO), Gim-P1c (GW+): Press the "Up/Down" arrow keys simultaneously for more than 3 seconds, then press "OK" key. Enter "Special Service Mode": Press and hold the "UP" and "DOWN" key simultaneously for at least 3 seconds, then press and hold the "ESCAPE" key for at least 3 seconds. NOTE: Gim-P1a does not have “Special Service Mode” Enter "Factory mode": Power the machine "ON" while pressing "Job Reset" and "DOWN" key simultaneously for at least 5 seconds. NOTE: In factory mode SP 5081-001 allows you to change the default SP entering code. WARNING: In case the “new” entering code is lost or forgotten, the NVRAM on the CTL BD needs to be replaced! IMPORTANT NOTE! Please treat this document as confidential and do not distribute freely. For internal (RFG authorised personnel) use only.
|
