السلام عليكم
اخواني الكرام ماذا يمكن ان اصمم بهذه القطعة D9259 بالاخص اذا كانت دارة للتحكم بالمحركات

اخواني هذا ما هو مكتوب في الداتاشيت

5-CH MOTOR DRIVER D9259
DESCRIPTION Outline Drawing
The D9259 is a monolithic integrated circuit,
and suitable for 5-ch motor driver which drivers
focus actuator, tracking actuator, sled motor,
spindle motor and loading motor of CD system.
FEATURE
z 1 phase, full-wave, linear DC motor driver.
z Built-in TSD (Thermal shutdown) circuit.
z Built-in 5V regulator (with an external PNP TR).
z Built-in mute circuit.
z Built-in loading motor speed control circuit.
z Wide operating supply voltage range: 6V~13.2V
TARGET APPLICATION
z CD-PLAY z VIDEO-CD z CAR-CD
